快速选型

RF射频同轴连接器

射频 (RF) 同轴连接器具有尺寸小，具有严格公差电气特性，频带宽、高频传输能力、‌高精度连接和耐用性强和长寿命。这些连接器通过压接、焊接和夹具端接制成，易于安装。

请注意，如果您需要标准天线上的特定连接器或电缆长度，可以根据您的特定要求进行定制。

产品名称及描述	连接器类型	外观形状	连接方式	连接器系列	接线方式	触点类型	端口数	频率(MZH)	驻波比	插入损耗	适配线缆	颜色	尺寸	产品合规性
13.5mm SMA-K 直头端口射频连接器 A-SMA-KE-13.5A 样品报价查看产品	[SMA-Connector]	[Right-Angle]	[Through-Hole]	[SMA]	[Wire-Solder]	[Female]	[1]	[0-6GHz]	[≤ 1.4]	[0.25dB（max）]	[-]	[Gold]	[6.5*13.5mm]	[RoHS]
A-SMA-KE-16.5A直头端口射频连接器 A-SMA-KE-16.5A 样品报价查看产品	[SMA-Connector]	[Right-Angle]	[Through-Hole]	[SMA]	[Wire-Solder]	[Female]	[1]	[0-6GHz]	[≤ 1.4]	[0.25dB（max）]	[-]	[Gold]	[6.5*16.5mm]	[RoHS]
A-IPEX1-1.25A 板端座子 A-IPEX1-1.25A 样品报价查看产品	[SMA-Connector]	[Right-Angle]	[Through-Hole]	[IPEX1]	[SMT/SMD]	[Female]	[1]	[0-6GHz]	[≤ 1.5]	[>0.5dB]	[-]	[Gold]	[6.5*16.5mm]	[RoHS]
A-IPEX3-0.85A三代板端座子适用于I-P EX MHFI、I-PEX MH FII、I-PEX MHFHT、UMC，CM A-IPEX3-0.85A 样品报价查看产品	[SMA-Connector]	[Right-Angle]	[Through-Hole]	[IPEX3]	[SMT/SMD]	[Female]	[1]	[0-6GHz]	[≤ 1.5]	[>0.5dB]	[-]	[Gold]	[6.5*16.5mm]	[RoHS]
